13 used wire and sinker EDM machines for sale, including wire cut machines for punches, dies and profiles, and die sinking machines for mould cavities, from FANUC, Sodick, Charmilles, Mitsubishi and other manufacturers. Every listing shows the year, condition and location, and you contact the seller directly.
Used wire and sinker EDM machines on MachineLinker
The 13 machines listed here come from 1 seller and are located in the Czech Republic (13). The used machines were built between 1998 and 2020; half of them in 2005 or later.
What to check before buying a used EDM machine
Travels and workpiece
X, Y and Z travels, maximum workpiece size and weight and, on wire machines, the maximum taper angle and workpiece height.
Generator and control
The generator and CNC control, the cutting speed and surface finish it reaches, and whether your CAM programs work with it.
Wire and threading
Wire diameters, automatic wire threading and whether it works reliably, and the wire chopper or take-up system.
Dielectric and filters
Deionised water, resin, filters and chiller on wire machines; dielectric oil, filters and fire protection on sinker machines.
Hours and accuracy
Machine and cutting hours, service records, and a test cut with the measured accuracy.
Frequently asked questions
What does an EDM machine do?
EDM (electrical discharge machining) removes metal with thousands of small electric sparks between an electrode and the part, inside a dielectric fluid. It cuts hardened steel, carbide and other conductive materials without cutting force, so it makes precise dies, punches, moulds and fine contours.
Wire EDM or sinker EDM: what is the difference?
A wire EDM cuts through the part with a thin brass or coated wire guided by the CNC, in deionised water: it makes punches, dies and profiles. A sinker (die sinking) EDM pushes a shaped graphite or copper electrode into the part, usually in oil, to make blind cavities such as mould cavities and ribs.
How much does a used EDM machine cost?
It depends on wire or sinker EDM, the travels and maximum workpiece, the generator and CNC control, the automatic wire threading and the age. The sellers in this category list their machines with “Price on request”: use the contact form, phone or WhatsApp on each listing to ask for a quote.
